Mohindra Mechanical Works

Features

• Number of Colors: 1 - 8 colors
• Web Width: 20" to 80"
• Web Roller: Aluminum or steel rollers
• Machine Speed: Up to 250 m/min
• Unwind Type: Single fixed shaft or two-shaft turret
• Reel Diameter: 1000 mm approx
• Unwind Shaft: Air shaft, taper cone with solid shaft or shaftless
• Tension Controller: Manual & auto registration (A.C. Motor)

In Feed Unit

• Synchronized Control (A.C. Motor)

Printing Unit

• Frame: Cast Iron
• Cylinder Diameter: 100 mm to 300 mm
• Chucking: Shaft with taper cone
• Drying System: Single chamber impingement slot dryer (Electric, Thermic Oil, Hot Air Generator)
• Doctor Blade: Manual & pneumatic
• Ink System: S.S. ink tray
• Registration System: Manual & Auto Registration (A.C. Motor)

Out Feed Unit

• Synchronized Control (A.C. Motor)

Rewinder

• Reel Diameter: 1000 mm approx
• Rewind Shaft: Air shaft, taper cone with solid shaft or shaftless
• Tension Controller: Manual & fully automatic control system (A.C. Motor)
